Modes & Contexts

• We’ve talked about our code being suggestions
• Which the browser can ignore

• But we also referred to declarations
• As style hints

• Sometimes they carry
• Seemingly simple concepts
• width of a box

• More abstract concepts
• wrapping text so it looks ‘pretty’
• (whatever that means)

• But even ‘simple’ declarations contain subtext
• What do we mean by a pixel?
• Should this box get smaller on a screen with higher resolution?
• How should it respond to zooming in and out?

• Are we setting the width of the content box?
• (so padding and border are added to our width)

• Or the width of the entire box,
• so padding and border are subtracted to get the content size?

• Maybe it’s not the width we care about exactly,
• that’s just the direction text flows.
• Are we trying to set the length of a line of text?

• Should it be based on the size of the font?

• Or maybe the box should re-size based on the contents inside?
• Their minimum or maximum size?

• Or based on context
• a parent element, viewport, or container

• Or some combination
• Like the minimum, of two values

• If we’re really trying to do this
• [Graphic design etc]

• There will be too many variables for us to consider on our own
• But the browser has all the context
• This is the strength of a declarative language…

• Where we describe the behavior we want to opt into
• Rather than the steps to achieve that behavior
• We don’t have to plan for all the outcomes, step by step
• most useful tools in CSS
• express somewhat abstract concepts
• let the browser work out details

• it’s powerful because we’re giving up control
• the browser knows more than we do

• To quote a book on directing for the theater…
• [quote]
• That’s our job, as UX designers & engineers
• To allow for that breadth of human experience
• Across different web contexts

• like theater, or language generally, CSS relies on subtext
• We don’t just state the outcome (a box that is 500px wide)
• But we provide hints about how we got to that result

• Sometimes two words can have the same surface meaning
• But they carry different implications
• In CSS, units are great at this
• (It’s why we have so many)
• 1em sometimes gives the same result as 16px
• But they have different meaning
• So they will adapt differently to context

• Similar with layout methods
• We can sometimes get the same result
• using either flexbox or grid (for example)
• but they move differently
• Respond to context and content differently

• So, like writing poetry
• We want to be careful in our choice of words
• To say more, without adding unnecessary constraints
• Providing subtle hints will often take us farther
• That a brute force approach

• As a result of this declarative model,
• CSS properties tend to be intertwined
• Their behavior isn’t isolated,
• (and can’t be isolated by using extreme conventions)

• In fact, many CSS properties are modal
• Some properties are used to set the current mode
• And some properties only apply in specific modes
• Or behave differently depending on the mode

• Most obvious with display properties…

demo:

• create span with text & outline
• add width
• add height
• add display: block, then display: list-item
• not just display of the element itself…
• add body { display: flex; }
• remove display: block etc
• change width to be large
• add float
• remove body display value

• So the display property is doing multiple things.
• We usually set a single value,
• but it acts like a shorthand
• Setting the outer mode of the element,
• (how it behaves in the parent context)
• And the inner mode…

• Which describe a formatting context for children
• A way of ‘flowing’ elements together,
• So that each element takes the space it needs,
• And pushes the other elements aside, to avoid overlap
• In CSS, we’re almost always in one of these modes,
• unless we explicitly…

• Pull elements out of the flow
• Which can be done element-by-element
• Using ‘floats’ or ‘absolute’ positioning
• Which are their own sort of layout modes
• With their own rules

• This push and pull of context and content
• is the fundamental tension of CSS
• We have some amount of space available
• And some amount of content to fit in that space

• Starting from a source document (html)
• Organized into a nested ‘tree’
• of Elements & Text Nodes
• Rendered onto…

• An infinite canvas!

• That sounds daunting,
• But we interact with that canvas…

• Through a finite viewport
• Our ‘window’ for viewing a website

• The parent of the root element
• We can’t style (directly)
• Has a finite width/height

• Provides the ‘initial’ containing block
• The outermost context
• For our tree of boxes
• Part of that context is…

• The document flow
• The way that documents are written
• In English we start at the top left,
• and move towards the bottom right

• With words that stack together into lines
• We call the direction of text flow the ‘inline axis’
• But that depends on…

• …The writing mode of the language
• So the inline axis is not always the width
• Some languages are written in vertical lines
• So the inline-axis will be the height instead
• But flow doesn’t only have an axis…

• …It has a direction,
• Which can also change based on the language
• A right-to-left language (like Arabic)
• will have horizontal lines of text
• But the direction of flow is reversed

• As lines fragment, they stack together on the block axis
• Forming block boxes
• Again the axis and direction of block flow
• Depends on the language and writing mode
• For English, it’s a vertical axis, top to bottom
• But in Korean, Chinese, and Japanese languages
• Where the lines of text can flow vertically
• The resulting blocks would stack horizontally (right to left)

• So in addition to our physical dimensions,
• Width and height, which are fixed in place
• We can talk about…

• The ‘flow-relative’ or ‘logical’ dimensions
• Based on the flow of text in a given writing mode
• English flows in lines from left to right
• And stacks in blocks from top to bottom
• (Horizontal, top to bottom)
• These are not fixed, but change based on the language

• That also gives us four logical sides
• Top, right, bottom, and left are fixed in place
• But block-start, block-end,
• Inline-start, and inline-end
• Orient us based on writing axis and direction

• Most design is relative to flow
• English sites put the logo top right
• Because that’s where we start reading English documents
• There are a few exceptions (eg shadows)
• As always, CSS is expressive
• Best to say what you mean

• We can start to replace our habits & old code
• Reaching for the logical equivalents instead
• Replacing properties like margin-right with margin-inline-end
• It will help if you ever provide page translations
• But also as browsers auto-translate

• Design interfaces that re-orient efficiently
• Without making other changes in CSS

• While some of the long-hands are a bit longer
• We don’t only save time doing multi-lingual sites
• We also get handy block and inline shorthands
• e.g. margin-block, padding-inline, border-block
• I use these all the time!

• Note that they cascade separately
• We don’t know until layout time if they will conflict
• Because the writing mode has to cascade as well
• If they do conflict, we compare cascade priority again
• Determine which should apply

• Inside of that flow,
• We have this tree of elements and text nodes

• Every element generating it’s own box by default

• Each box has four areas
• (content, border, padding, and margin)
• (B/P/M have their own properties)
• But each of them…

• Has an outer box edge that we can reference
• Using keywords
• In addition to the box properties & keywords…

• Even text nodes inside of elements
• Get anonymous boxes
• Just means we can’t select or style them directly
• Have to select the parent element instead

• We can use the display property
• To manipulate box generation on elements…

• Display-none will remove the box
• (including everything inside)
• So neither the box or the contents are rendered.

• Display-contents will remove the box
• But leave the contents in place
• This can be helpful in some situations,
• But we have to be careful…

• Can cause major accessibility issues in some browsers
• Removing the semantics of the element
• Or the elements inside, which is bad!
• Much of that has been fixed in recent releases,
• But not everyone is on the latest browsers, and…

• Most browsers still have issues on HTML buttons and tables
• So never use display:contents on those elements
• And be cautious on other semantic elements
• (links, lists, etc)
• Mostly use for adding/removing
• ‘wrapper’ divs when doing layout

• In addition to removing element boxes
• We can add them!
• The list-item display
• Generates an additional ::marker box
• Which we can move in or out of the principle box
• Let’s see all this in practice…

1. Box tree of elements and text nodes
2. Four areas: content, padding, border, & margin
3. Four edges: content-box, padding-box, border-box, margin-box
4. Each box provides a context for nested content to flow (inside the content-box)
5. HTML box is contained by Viewport
6. Display:none; (head/style) removes box & subtree
7. Display:contents; (figure?) removes box
8. Display:list-item; (li) generates a second ::marker box
9. List-style-position moves ::marker in or out of primary box

• The boxes that remain have to be laid out somehow
• And the default layout mode is called normal flow
• Designed to feel somewhat invisible and obvious
• It’s just the way we write documents…

• Some boxes flow in line with the text

• And some stack up, wrapping entire blocks

• Which gives us the outer display values

• As we saw earlier,
• The initial display value is inline,
• So all our boxes flow with the text by default
• Until the browser comes along…

• And defines some block boxes for us
• With space between them
• To make the document more readable

• Even though these are both part of Normal Flow
• They form somewhat distinct layout modes,
• Each with different rules
• Let’s take a look…

• Inline boxes flow with text nodes
• Have an intrinsic size
• Determined by the content inside
• Boxes expand (and stack together) ‘in lines’
• When a box reaches a container edge, it will fragment
• Creating a new ‘line’
• Can set line-height (initial normal from font metrics)
• But explicit boxes sizes are ignored
• Contribute border/padding/margins on the inline axis only
• Always participate in inline layout
• (add display block to get anonymous boxes)

• Inline boxes participate in an inline flow
• And only interact with other inline boxes
• If we mix block and inline boxes together
• we get a block flow with ‘anonymous boxes’ around text

• Take their inline-size from context (extrinsic)
• Always stretch by default
• Take their block-size from content (intrinsic)
• Blocks expand and stack flow on the block axis
• Contribute padding/margins on both axis
• Adjacent margins collapse
• Can be explicitly sized (intrinsic or extrinsic)

• Block boxes always participate in block layout,
• And as we saw earlier
• Will force a block layout when they show up,
• even if that requires extra anonymous boxes around text

• Inline boxes and text nodes get their inline size
• From the text itself, the contents of the box
• Explicit sizes are ignored

• Take their block-size from content

• This is the intrinsic size
• To find it, look down the tree at child boxes
• The content pushing out, taking up space

• Inline boxes get their block size from the line itself
• It doesn’t really matter what we put in there,
• the height of the box is the height of the line

• By default, blocks…
• Take their inline-size from context…

• Extrinsic sizing, we look up the tree, at the parent box
• There’s always a container pushing in, providing limits
• Extrinsic constraints
• And always content pushing out, taking up space
• An intrinsic size determined by whatever’s in there

• But extrinsic sizes don’t only come from the browser
• Any size that we set explicitly will be extrinsic
• It doesn’t come from the natural size of the content,
• But is imposed from the outside

• Have access to intrinsic sizing keywords
• Min-content, max-content, and fit-content

• We can also now select
• The box-edge to size from

• The default is content-box
• (useful for defining containers by the size of content)
• But it’s common to change that default
• With box-sizing: border-box on all elements
• You can include before & after pseudos if you want
• But I find they don’t usually need it (depends)

• The outer display values are sometimes ignored
• If we move an element into a grid
• No longer inline or block, just a ‘grid item’
• In a flex context, it becomes a ‘flex item’ (and so on)
• An inline element in a block context can be ‘blockified’

• These are ‘inner’ display values
• We set them on the parent, and they establish context for children
• Different formatting contexts or layout modes
• Such as flex, grid, table, or even ‘flow’
• You’ve maybe never set that last one explicitly
• Because keyword is newer, but…

• It’s the default when we only define an outer value
• block or inline means block flow, and inline flow
• Flow is the default, if we don’t specify another mode…

• Flex, or grid, or some form of table display
• When we just set an inner value (like grid or flex)
• Those come with a default block outer value
• And so we usually only set a single value
• Except in special cases…

• In normal flow,
• Margins collapse to give us reasonable spacing
• And floats ‘flow’ through neighboring boxes
• Pushing inline-content to one side, continuing to wrap
• But sometimes we want to break up our flow into discrete blocks
• Historically, solved floats with a ‘clearfix’
• Or overflow: hidden;

• Now we can ask for this explicitly
• Flow-root not just creating a new flow context
• But isolating it from outside interactions
• “a mini layout in your layout”

• Generates a new Block Formatting Context
• This is also what happens with overflow: hidden
• And some other ‘clearfix’ techniques

• Rachel Andrew has an excellent article
• With various demos to show what a BFC does
• Keeping floats contained

• Keeping external floats out

• The same with margins
• Don’t interact or collapse across the boundary

• While inline boxes are always sized to content
• Block and inline-block (or block flow-root) boxes
• Can have explicit sizes
• And contribute to the layout of both dimensions
• Allows nesting other layouts inside a line box…

• Which is otherwise not possible
• Since inline & block flow on a different axis
• The two don’t normally mix
• They separate (oil and water)

• If we put a block box inside an inline box
• Browsers add ‘anonymous’ blocks to separate
• Make it inline-block
• It joins the inline flow
• While still acting like a block box internally

• Well supported since 2019

• Why we have inline-flex, inline-grid, inline-block
• Create more complex layouts, that participate…

• As inline-level boxes
• In a parent flow of inline content
• The outer display is ‘inline’

• But their inside display value
• The layout context they create for children
• Is flex or grid or flow-root

• So these can get added to our list
• Single display values that represent
• Longer multi-value display behavior

• We call this new syntax multi-value display
• It is new, but becoming widely supported

• Don’t need to use new syntax
• Helpful to understand display
• Provide more clarity
• Flexibility to mix and match (if needed)

• Let’s look a bit closer at elements pulled out of flow
• With absolute positioning or floats
• These are specialized modes, with complex interactions
• Sometimes overriding the element’s outer display
• And often overriding the parent context as well
• There’s a chart in the CSS 2 spec
• For how these properties interact

• The spec considers fixed and absolute position
• To be variants of the same thing
• Not different ‘layout modes’
• Only different positioning anchors

• abspos overrides float
• both blockify the element
• change the anchor
• fit-content sizing

• All these tools help us express
• The intent of a layout
• The choices that we’re making
• And what to prioritize

• This meme perfectly captures what is actually awesome about CSS – and how we can go wrong by taking too much control without considering the consequences. So how can we lighten our grip here?

[demo] change to use intrinsic sizes
